詳細說明
| 貨號 | 430601000 | 430602000 | 430603000 | 430605000 | |
| 型號 | VIT010B | VIT020B | VIT030B | VIT050B | |
| 額定載荷 | (Ton) | 1 | 2 | 3 | 5 |
| 測試載荷 | (Kn) | 14.71 | 29.42 | 44.13 | 61.29 |
| 最小轉彎半徑 | (M) | 1 | 1.1 | 1.3 | 1.4 |
| 尺寸 | A | 270 | 305 | 320 | 360 |
| B | 204 | 233 | 280 | 306 | |
| C | 164 | 185 | 225 | 252 | |
| D | 45 | 60 | 65 | 75 | |
| 推薦用工字鋼 | (mm) | 75-125 | 100-150 | 100-150 | 125-175 |
| 裝箱尺寸 | 整裝 | 270×230×190 | 300×260×210 | 310×300×250 | 380×320×270 |
| 散裝 | 230×190×150 | 260×220×160 | 300×260×180 | 350×260×220 | |
| 凈重 | Kg | 11.6 | 16.1 | 24.7 | 37.1 |
| 毛重 | Kg | 12.4 | 17.0 | 25.6 | 38.6 |
